PHB-2*NALT 2.0mm Pitch Wire-to-Board Connector

KL-PHB-2×NALT

PHB-2XNALT

Product Shape, Dimensions and Material:

Current rating: 3.0 A

Rated voltage: 250V AC,DC

Temperature range: -25ºC~+85ºC

1 Wafer: PA or LCP， UL94V-0.

2 Contact: Brass; T=0.50mm; Finish: Tin plated.over Nickel plated

Harmful Material Should Be Compliant to Doc. “RoHS、REACH.” Standards.

The PHB-2*NALT 2.0mm Pitch Wire-to-Board Connector is a compact and high-precision electrical connector designed for secure and efficient connections between wires and printed circuit boards (PCBs). With a pitch of 2.0mm, this connector is ideal for applications requiring reliable electrical performance in a smaller footprint. Its advanced design and materials provide durability, stability, and versatility, making it suitable for a wide range of electronic devices and industrial systems.

Key Features

Compact Design

The 2.0mm pitch minimizes the space required on PCBs, allowing for compact product designs.

Ideal for applications with limited installation space, such as handheld devices and compact modules.

Reliable Electrical Connectivity

Low Contact Resistance: Ensures stable current and signal transmission with minimal energy loss.

Secure Terminal Engagement: Designed with precision locking mechanisms that maintain robust connections even under mechanical stress.

High Durability

Made with high-quality plastic housing and metal terminals to withstand repeated plug-and-unplug cycles.

Resistant to wear and tear, ensuring longevity in demanding applications.

Easy and Error-Free Installation

The keyed design prevents incorrect mating of the connector, ensuring proper orientation during assembly.

Supports quick and hassle-free installation, reducing labor time and assembly errors.

Versatile Pin Configurations

Available in multiple configurations (2 to N positions), allowing flexibility for different PCB layouts and wire count requirements.

Environmental Resistance

Built with materials resistant to heat, chemicals, and moisture, ensuring reliability in harsh environments.

Often rated for a wide temperature range, making it suitable for industrial and outdoor use.

Compliance with Industry Standards

Designed to meet or exceed safety and environmental compliance standards such as RoHS.

Applications

Consumer Electronics

Commonly used in devices like cameras, audio equipment, and wearable devices where compact and reliable connections are essential.

Automotive Electronics

Suitable for automotive lighting, sensors, and infotainment systems requiring vibration resistance and durability.

Industrial Automation

Used in control panels, sensors, and PLCs, providing robust connections for industrial equipment.

Telecommunications

Plays a role in networking equipment, modems, and base stations, ensuring efficient data and power transmission.
