The 2.54mm Double Row Female Pin Header features a compact, space-efficient design with a 2.54mm pitch (distance between pins). It consists of two parallel rows of pins, which are designed to connect with corresponding male pin headers or connectors. This double-row configuration allows for a higher density of connections, making it ideal for applications where space is limited but a high number of connections is required.
This pin header is typically constructed from high-quality plastic and metal materials. The plastic insulator provides structural support and electrical isolation, while the metal pins ensure reliable electrical conductivity. The pin header is designed for through-hole mounting, meaning it is inserted into holes in a printed circuit board (PCB) and soldered in place. This mounting method ensures a strong mechanical connection and excellent durability.
Advantages
High Density Connectivity
Compact Design: With a 2.54mm pitch, the double-row configuration allows for a large number of connections in a small footprint, which is essential for compact electronic devices.
Space Efficiency: This design maximizes the use of available space on the PCB, making it suitable for applications where real estate is at a premium.
Durability and Reliability
Robust Construction: The use of high-quality plastic and metal materials ensures that the pin header can withstand mechanical stresses and environmental conditions.
Stable Electrical Connections: The precision engineering of the pins and the careful design of the insulator contribute to stable and reliable electrical performance, reducing the risk of connection failures.
Ease of Use
Simple Assembly: The through-hole mounting method simplifies the assembly process and ensures that the pin header is securely attached to the PCB.
Versatile Compatibility: The 2.54mm pitch is a standard size that is compatible with a wide range of male pin headers and connectors, making it easy to integrate into various designs.
Key Features
Precision Pin Design
Accurate Pitch: The 2.54mm pitch is precisely maintained to ensure accurate alignment with male connectors, which is critical for reliable electrical connections.
Straight Pins: The straight pin design facilitates easy insertion into the PCB and ensures a secure fit.
High-Quality Insulator
Electrical Insulation: The insulator is made from high-quality plastic that provides excellent electrical insulation and prevents short circuits.
Mechanical Strength: The plastic material is designed to withstand mechanical stresses during assembly and use, ensuring long-term reliability.
Versatile Mounting Options
Through-Hole Mounting: This mounting method is compatible with various PCB designs and is widely used in both manual and automated assembly processes.
Customizable Configurations: While the standard 2.54mm Double Row Female Pin Header is widely used, custom configurations are available to meet specific design requirements.
Applications
The 2.54mm Double Row Female Pin Header is used in a broad range of applications, including different kinds of home appliances for interconnecting components.
The 2.54mm Double Row Female Pin Header is a versatile and reliable component that plays a critical role in modern electronic assembly. Its compact design, high-density connectivity, and durable construction make it an essential choice for a wide range of applications.
